The usage methods and precautions for low-temperature wastewater recovery equipment are as follows:

使用方法：

Usage:

(1) 進液：通過外部泵浦將高濃度液進入計量裝置水罐，真空壓力達到時自動閥門開啟吸入釜槽內，完成進液與計量。

(1) Liquid inlet: High concentration liquid is pumped into the water tank of the metering device through an external pump. When the vacuum pressure reaches, the automatic valve is opened and sucked into the tank to complete liquid inlet and metering.

(2) 加熱：進液完成后打開蒸汽閥門透過夾套對廢液進行加熱，與危廢中的水分行熱交換，為降低含水率提供熱能。

(2) Heating: After the liquid inlet is completed, open the steam valve to heat the waste liquid through the jacket, and exchange heat with the water in the hazardous waste to provide heat energy to reduce the water content.

(3) 蒸餾：直空泵對整體環節抽直空至-80到-90kPa。水分在約45°C即沸騰蒸發低溫狀態可避免其他物質因高溫而二次質變。直空環境使水蒸發條件雨有效讓今水率降低雨快。通過攪拌裝置避免焦結成塊。

(3) Distillation: The straight air pump directly empties the entire process to -80 to -90kPa. The low temperature state of boiling evaporation of water at about 45 ° C can avoid secondary transformation of other substances due to high temperatures. The direct air environment allows for water evaporation, which effectively reduces the current water rate and accelerates rainfall. Avoid coking and agglomeration through a stirring device.

(4) 排渣：加熱過程攪拌均勻受熱，可設定蒸煮周期與批次后，將釜殘透過攪拌裝置自動排出，完成排出工作。

(4) Slag discharge: During the heating process, stir evenly and receive heat. The cooking cycle and batch can be set, and the residue in the kettle can be automatically discharged through the mixing device to complete the discharge work.

(5) 排水：危廢中蒸發的水蒸氣通過冷凝裝置成為干凈的蒸餾回收水，于回收水槽存放，透過泵將回收水依照客戶規劃進行后續使用。

(5) Drainage: The evaporated water vapor from hazardous waste is condensed into clean distilled and recycled water through a condensing device, stored in a recycling tank, and pumped through a pump for subsequent use according to customer plans.

注意事項：

Precautions:

(1) 確保鍋爐正常工作；

(1) Ensure the normal operation of the boiler;

(2) 安裝前應先檢查一下鍋爐是否有泄漏和滲漏現象；

(2) Before installation, the boiler should be checked for any leaks or leaks;

(3) 在操作中如果遇到問題，請及時聯系人員解決；

(3) If you encounter any problems during operation, please contact professional personnel in a timely manner to solve them;

(4) 安裝結束后，要對系統進行調試，以保證順利啟動。

(4) After installation, the system needs to be debugged to ensure smooth startup.

以上是低溫廢水回收設備的使用方法及注意事項供您參考。

The above are the usage methods and precautions for low-temperature wastewater recovery equipment for your reference.
