Main parameters of ultrasonic cleaning machine

超聲波清洗是基於空化作用，即在清洗液中無數氣泡快速形成并迅速內爆。由此產生的沖擊將浸沒在清洗液中的工件內外表面的污物剝落下來。隨著超聲頻率的提高，氣泡數量增加而爆破沖擊力減弱，因此，高頻超聲特別適用於小顆粒污垢的清洗而不破環其工件表面。氣泡是在液體中施加高頻（超聲頻率）、高強度的聲波而產生的。因此，任何超聲清洗系統都具備三個基本元件：盛放清洗液的槽、將電能轉化為機械能的換能器以及產生高頻電信號的超聲波發生器。

Ultrasonic cleaning is based on cavitation, that is, numerous bubbles in the cleaning solution form and implode rapidly. The resulting impact will peel off the dirt on the inner and outer surfaces of the workpiece immersed in the cleaning fluid. With the increase of ultrasonic frequency, the number of bubbles increases and the blasting impact force decreases. Therefore, high-frequency ultrasonic is especially suitable for cleaning small particles of dirt without breaking the workpiece surface. Bubbles are produced by applying high-frequency (ultrasonic frequency) and high-intensity sound waves to the liquid. Therefore, any ultrasonic cleaning system has three basic components: a tank containing cleaning fluid, a transducer that converts electrical energy into mechanical energy, and an ultrasonic generator that generates high-frequency electrical signals.

(1)頻率：≥20KHz ，可以分為低頻，中頻，高頻3段。

(1) Frequency: ≥ 20kHz, which can be divided into low frequency, medium frequency and high frequency.

(2)清洗介質：采用超聲波清洗，一般兩類清洗劑：化學溶劑、水基清洗劑等。清洗介質的化學作用，可以加速超聲波清洗效果，超聲波清洗是物理作用，兩種作用相結合，以對物件進行充分的清洗。

(2) Cleaning medium: ultrasonic cleaning is adopted. Generally, there are two types of cleaning agents: chemical solvent and water-based cleaning agent. The chemical action of the cleaning medium can accelerate the ultrasonic cleaning effect. Ultrasonic cleaning is a physical action. The two actions are combined to fully clean the objects.

(3)功率密度：功率密度=發射功率（W）/發射面積（cm2）通常≥0.3W/cm2，超聲波的功率密度越高，空化效果越強，速度越快，清洗效果越好。但對于的、表面光潔度甚高的物件，采用長時間的高功率密度清洗會對物件表面產生“空化”腐蝕。

(3) Power density: power density = emission power (W) / emission area (cm2) usually ≥ 0.3w/cm2. The higher the power density of ultrasonic wave, the stronger the cavitation effect, the faster the speed, and the better the cleaning effect. However, for objects with high surface finish, long-time high-power density cleaning will produce "cavitation" corrosion on the surface of the objects.

(4)超聲波頻率：超聲波頻率越低，在液體中產生的空化越容易，產生的力度大，作用也越強，適用于工件（粗、臟）初洗。頻率高則超聲波方向性強，適用于精細的物件清洗。

(4) Ultrasonic frequency: the lower the ultrasonic frequency is, the easier the cavitation will be generated in the liquid. The greater the intensity and the stronger the effect will be. It is suitable for the initial cleaning of workpieces (coarse and dirty). High frequency means strong ultrasonic directivity, which is suitable for fine object cleaning.

(5)清洗溫度：一般來說，超聲波在30℃-40℃時的空化效果好。清洗劑則溫度越高，作用越顯著。通常實際應用超聲波時，采用50℃-70℃的工作溫度。

(5) Cleaning temperature: Generally speaking, the cavitation effect of ultrasonic at 30 ℃ -40 ℃ is good. The higher the temperature of cleaning agent, the more significant the effect. Generally, the operating temperature of 50 ℃ -70 ℃ is used in the actual application of ultrasonic.

工業超聲波清洗機使用注意事項：

Precautions for use of industrial ultrasonic cleaning machine:

(1)超聲波清洗機電源及電熱器電源有良好接地裝置。

(1) The power supply of ultrasonic cleaning machine and electric heater shall be well grounded.

(2)超聲波清洗機嚴禁無清洗液開機，即清洗缸沒有加一定數量的清洗液，不得合超聲波開關。

(2) It is strictly forbidden to start the ultrasonic cleaning machine without cleaning fluid, that is, the ultrasonic switch shall not be turned on if a certain amount of cleaning fluid is not added to the cleaning cylinder.

(3)有加熱設備的清洗設備嚴禁無液時打開加熱開關。

(3) For cleaning equipment with heating equipment, it is forbidden to turn on the heating switch when there is no liquid.

(4)禁止用重物(鐵件)撞擊清洗缸缸底，以免能量轉換器晶片受損。

(4) It is forbidden to strike the bottom of the cleaning cylinder with heavy objects (iron pieces) to avoid damage to the energy converter chip.

(5)超聲波發生器電源應單獨使用一路220V/50Hz電源并配裝2000W以上穩壓器。

(5) The power supply of ultrasonic generator shall use one 220v/50hz power supply separately and be equipped with a voltage regulator above 2000W.

(6)清洗缸缸底要定期沖洗，不得有過多的雜物或污垢。

(6) The bottom of the cleaning cylinder shall be washed regularly without too much sundries or dirt.

(7)每次換新液時，待超聲波起動后，方可洗件。

(7) Each time the liquid is changed, the parts can be washed only after the ultrasonic wave is started.

超聲波清洗機的其它應用

Other applications of ultrasonic cleaning machine

超聲波清洗機除用于清洗外，還可以廣泛的應用于脫氣、消泡、乳化、混勻、置換、提取、粉料粉碎及細胞粉碎。其中液相脫氣已成為超聲波清洗機除清洗外的一個主要應用之一，也成為液相儀器工具之一。

In addition to cleaning, ultrasonic cleaning machine can also be widely used in degassing, defoaming, emulsification, mixing, replacement, extraction, powder crushing and cell crushing. Liquid phase degassing has become one of the main applications of ultrasonic cleaning machine besides cleaning, and also one of the liquid phase instrument tools.

以上就是為大家介紹的有關超聲波清洗機設備的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://m.chinalssc.com

The above is a detailed introduction to the ultrasonic cleaning machine. I hope it will help you If you have any questions, please contact us We will provide you with professional service http://m.chinalssc.com
